Room For Big Models
A 300 x 300 mm bed with 400 mm of headroom leaves space for large single-piece prints, tall models, or a full plate of smaller parts in one run.
MA10 Highlights
Large-Format FDM 3D Printer
MA10 pairs a roomy 300 x 300 mm bed with 400 mm of height, so large or complex models print in one piece. A flexible magnetic sheet, a protected power supply and a steel frame keep it practical for everyday use.
Flexible Magnetic Build Sheet
The heated bed takes a flexible magnetic sheet. Lift it off and flex it and the print releases, which also makes cleaning the bed straightforward.
Auto Bed Leveling And Print Resume
The bed levels itself rather than being set by hand, and the printer picks a job back up after a power failure instead of losing it.
Protected GVE Power Supply
MA10 ships with a GVE power supply rated for fast heat-up and long continuous prints, and it shields the printer from unexpected power surges.
Steel Frame For Steadier Motion
A steel structure keeps the frame rigid. That holds motor accuracy over long prints and shows up as cleaner surfaces on the finished part.
Technical Details
MA10 Specifications
Model
MA10
Printing Technology
FDM
Max Printing Size
300 x 300 x 400 mm
Nozzle Diameter
0.4 mm
Filament Diameter
1.75 mm
Supported Filament Types
PLA, PETG
Hotend Setup
Bowden
Print Speed
Recommended 60 mm/s
Max Extruder Temperature
250 °C
Max Build Plate Temperature
90 °C
Bed Leveling
Automatic
Build Plate
Flexible removable magnetic build sheet
Display
LCD screen
Connectivity
Micro USB, MicroSD card
Slicing Software
Cura, Repetier-Host
Operating System
Windows, Linux, Mac
Power Supply
100-120 V / 200-240 V, 50/60 Hz
Frame
Steel construction
Weight
9 kg (19.8 lb)
Support / Contact
Need Help With This Printer?
For quotation requests, firmware, software, manuals or product support, contact us and we will respond within 24 hours.
